Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod
Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod

Vixen Sphinx SXD2 Delux German Equatorial Mount & Tripod

X000006-X000023

Regular price€3.250,00
/
(Including VAT)

Vixen has developed a new generation of SX mounts for demanding observers and astrophotographers. The SXD2 mount comes with the new StarBook 10 control feature and be operated manually or with a computer. Featuring the same precision stepper motors as the top-of-the range AXD mount, the SXD2 sets a new standard for performance and precision in the Vixen mount range.

Precision stepper motors and micro-step motion control system:
The star feature of the SXD2 is the precision stepper motors, which offer better performance and responsiveness than previous models. The micro-step motion control system has powerful yet very quiet drive characteristics that offer both fine control and quick swivel movements.

Built-in bearings:
The bearings of the RA and DEC axles and the worm shafts were significantly improved in order to reduce the load on the motors. The motors are much quieter than those on previous models.

High-precision worm gears:
High-precision processing technologies were used to rectify problems with the worm gear. The edges of both worms and worm gears are particularly smooth, which enables them to deliver very high precision.

Declination axis functions as counterweight:
The sturdy motor units are built into the bottom of the declination axis to ensure that the SDX2’s centre of gravity is below the intersection of the RA and DEC axis. As a result, fewer additional counterweights are required.

Robust and Sturdy Aluminium Tripod:

A High-quality, stable aluminium tripod for a variety of mounts with 45 mm connections. The aluminium profile ensures firm positioning with a minimum amount of vibration.

Weight & Dimensions:

  • Total length: 360 mm
  • Total width: 120 mm
  • Total height: 360 mm
  • Net weight (without access.): 8.8kg
Specs:
  • Mount type: Equatorial
  • Max Payload: 20kg (15kg Astrophotography)
  • Latitude adjustment range (degrees) (approx.) from 0
  • Latitude adjustment range (degrees) (approx.) up to 70
  • Colour: white
  • Body material: Aluminium
  • Material : Aluminium
  • Mount Type: German/Equatorial Mount with GoTo
  • R.A. Sprocket: 180 teeth
  • DEC sprocket: 180 teeth
  • Bearings: Carbon steel / decl. 35 mm RA 40 mm thickness
  • Polar finder telescope: 6x20 mm PFL polar viewfinder
  • Height fine adjustment: 0° to70°, (+/- 15° fine adjustment, height)
  • Azimuth adjustment Twin-screw fine adjustment
  • Control: StarBook 10
  • Power supply: DC 12 V; 0.4~1.7 A
  • Counterweight: 1x 1.9 kg and 1x 3.7 kg
  • Dimensions: 36 cm (H) x 12 cm (W) x 36 cm (L)
  • Weight: 8.8 kg (19.4lb), without counterweight
Whats included:
  • Sphinx SDX2 Mount
  • Sturdy Vixen Aluminium Tripod
  • Starbook 10 Controller
  • 1.9 kg and 3.7 kg counterweight
  • PFL-II polar viewfinder
  • Cigarette lighter cable
